EP 445
A 19th century style LED lantern to refurbish historic city centers and streets with a durable and efficient solution
- Combines a 19th-century look with 21st-century performance. This retro-style lantern is the perfect replacement for traditional lighting in historic locations.
- IDA (Dark Sky Approved) fixture seal of approval relates to <= 3000 K only and clear enclosures. ENEC certified.
- Extended lifetime with limited lumen depreciation (L90 for 100 000 hours) creating a long-lasting light ambiance. This highly efficient replacement solution provides up to 150 lm/W (4000 K) and up to 145 lm/W (3000 K).
- Made of die-cast aluminium for robustness and corrosion protection and with a textured black finish, EP445 brings a modern twist to a traditional design.
- A high-quality optical system significantly increases performance when replacing old light sources. Colour temperatures of 4000K, 3000K and 2700K are available as standard.
- Quick installation with choice of suspended and post-top mountings to cover applications ranging from residential streets to city squares. Highly maintainable according to circular design rules.
Wykonanie
Lantern body and top: die-cast aluminium, black textured finish (RAL 9005), standard corrosion class: C3 (ISO 9223)
Gasket: silicone
Enclosure: extra clear 4 mm glass
Montaż
The recommended height is up to 6 metres for post-top or suspended mounting.
Post top:
On steel Meleze columns Ø 60mm with adaptor (code 96629564).
On die-cast columns with threaded spigot.
Suspended:
Fixing on Andely and Le Mail brackets or consoles through Ø 27G threaded tube.
Universal joint code 96262636 allowing compensation of any possible default of verticality support in case of straight fixing.
Access the replaceable LED plate via four screws after opening the hinged canopy with one screw. Automatic disconnection feature to prevent damage when opening the luminaire. Supplied in a kit for assembly in three easy steps.
Pre-wiring can be added in a fourth step before installation on the pole. A 5 m H07RN-F cable is supplied as standard for the post-top version and everything is supplied in one box.
Opis
To specify state:
IP66 post-top and suspended, 19th century style die-cast aluminium lantern with up to 150 lm/W efficiency, a black textured finish, asymmetrical and rotational symmetric optics, a dimming system, and coordinated columns and brackets. Automatic disconnection feature.
As Thorn EP 445
